Waste water drainage in factories, construction and commercial facilities.
Drainage system in municipal sewage treatment plants.
Drainage station in residential quarters.
Municipal projects.
Methane pools and field irrigation in countryside.

Max.Depth:5m
Max.fluid temperature:40℃
Liquid PH value:4-10
Liquid kinematic viscosity: 7×10^-7--23×10^-6 m²/s
Max.liquid density: 1.2×10³ kg/m³

Copper winding
Built-in thermal protector
Continuous service S1
Insulation Class B
Protection IPX8

Pump body: Cast iron
Motor housing: AISI304 SS
Impeller:PA 66, 30%Fiber
Motor shaft: Carbon steel
Mechanical seal: Ceramic-Graphite
Cable length: 5.3m
