Waste water drainage in factories, construction and commercial facilities
Drainage system in municipal sewage treatment plants
Drainage station in residential quarters
Municipal projects
Methane pools and field irrigation in countryside

Max.Depth:5m
Max.fluid temperature:40℃
Liquid PH value:4-10
Liquid kinematic viscosity: 7×10^-7--23×10^-6 m2/s
Max.liquid density: 1.2×10³ kg/m³

Copper winding
Built-in thermal protector
Continuous service S1
Insulation Class B
Protection IPX8

Pump body: Cast iron
Motor housing: AISI304 SS
Impeller: Cast iron
Motor shaft: Carbon steel
Mechanical seal: Ceramic-Graphite
Cable length: 10m
