Your Location: Home > Products > 60HZ PumpsProname:JDW
I want to enquire

Model Power
(HP)
Voltage
(V)
Frequency
(Hz)
Current
(A)
Max.head
(ft)
Max.flow
(GPH)
Intlet/Outlet G.W.
(kg)
Packing size
(mm)
QTY/20'
(PCS)
JDW-60 1/2 115/230 60 6.4/3.2 123 681 NPT1-1/4"×NPT1" 15 430×310×250 840
JDW-80 3/4 115/230 60 7.8/3.9 141 729 NPT1-1/4"×NPT1" 16 430×310×250 840
JDW-100 1 115/230 60 10/5 164 808 NPT1-1/4"×NPT1" 17 430×310×250 840


For deep well

Model Power
(HP)
Max.Suct
(ft)
Max.head
(ft)
Max.flow
(GPH)
JDW-60 1/2 65 85 317
JDW-80 3/4 82 98 396
JDW-100 1 82 114 396
